DYP Series pressure spray dryer（Mixing-flow type）

HOME > Produts > Spray dryer Spray dryer

< >

Keywords:

This machine is a kind of special drying equipment aimed at the final products with special technical requirements on granularity liquidity, residual moisture content, particle loosening, and particle density and so on.

Order

Detail Picture

Description:
This machine is a kind of special drying equipment aimed at the final products with special technical requirements on granularity liquidity, residual moisture content, particle loosening, and particle density and so on. It integrates the drying and granulating into one single process, simplifying the production process, saving lots of manual labor and processing procedures.

This machine has special requirements on the liquid preparation process before drying. It needs strictly control and regulation according to the property of the material. Now it is widely used in ceramics, ferrite, magnetic materials, etc.

Technical parameters:

Type	6			12.5	25	50	65	100	150	200	400	600	800
Maximum water evaporation (Kg/h)	6			12.5	25	50	65	100	150	200	400	600	800
Spraying form		The pressure spray nozzle with low pressure
Spray pressure (Mpa)		0.6~2.5
Heat source (options)			fuel Oil ,natural gas ,coal gas, coal, electricity and so on.
Note: The water evaporation is related to the property and solid content of the material and the temperature of the air inlet and outlet.

The machine can press the liquid material into the spray nozzle located at the middle section of the tower ,and then the spray nozzle make the liquid into the tiny droplet. The tiny droplet will mix flow with hot air and finish the drying .(the liquid material is prayed from down to up, hot air flows from up to down). The dried products are with the features of
Good flow ability, uniform particles etc.

Process flow diagram:
